IEC 62077 pdf download.Fibre optic circulators – Generic specification
This International Standard applies to circulators used in the field of fibre optics bearing all of the following features: – they are non-reciprocal optical devices, in which each port is either an optical fibre or optical fibre connector; – they are passive components containing no opto-electronic or other transducing elements; – they have three or more ports for directionally transmitting optical power. This standard establishes uniform requirements for the following: – fibre optic circulator requirements; – quality assessment procedures.
1.2 Normative references
The following normative documents contain provisions which, through reference in this text, constitute provisions of this International Standard. For dated references, subsequent amendments to, or revisions of, any of these publications do not apply. However, parties to agreements based on this International Standard are encouraged to investigate the possibility of applying the most recent editions of the normative documents indicated below. For undated references, the latest edition of the normative document referred to applies. Members of IEC and ISO maintain registers of currently valid International Standards. IEC QC 001001:1998, IEC Quality Assessment System for Electronic Components (IECQ) – Basic rules IEC QC 001002-2:1998, IEC Quality Assessment System for Electronic Components (IECQ) – Rules of Procedure – Part 2: Documentation IEC QC 001002-3:1998, IEC Quality Assessment System for Electronic Components (IECQ) – Part 3: Approval procedures IEC Guide 102:1996, Electronic components – Specification structures for quality assessment (Qualification approval and capability approval IEC 60027 (all parts), Letter symbols to be used in electrical technology IEC 60050(731):1991, International Electrotechnical Vocabulary (IEV) – Chapter 731: Optical fibre communication IEC 60410:1973, Sampling plans and procedures for inspection by attributes IEC 60617 (all parts), Graphical symbols for diagrams IEC 60695-2-2:1991, Fire hazard testing – Part 2: Test methods – Section 2: Needle-flame test IEC 60825-1:1993, Safety of laser products – Part 1: Equipment, classification, requirements and user’s guide IEC 61300-1:1995, Fibre optic interconnecting devices and passive components – Basic test and measurement procedures – Part 1: General and guidance IEC 61300-2 (all parts), Fibre optic interconnecting devices and passive components – Basic test and measurement procedures – Part 2: Tests IEC 61300-3 (all parts), Fibre optic interconnecting devices and passive components – Basic test and measurement procedures – Part 3: Examinations and measurements IEC 61930:1998, Fibre optic graphic symbology ISO 129:1985, Technical drawings – Dimensioning – General principles, definitions, methods of execution and special indications ISO 286-1:1988, ISO system of limits and fits – Part 1: Bases of tolerances, deviations and fits ISO/FDIS 1101, Geometrical Product Specifications (GPS) – Geometrical tolerancing – Tolerances of form, orientation, location and run-out 1) ISO 8601:1988, Data elements and interchange formats – Information interchange – Representation of dates and times
For the purpose of this International Standard, the definitions given in IEC 60050(731), together with the following definitions, apply. 1.3.1 fibre optic circulator passive component possessing three or more ports numbered sequentially (1, 2,—–, n) through which optical power is transmitted non-reciprocally from port 1 to port 2, from port (i) to port (i + 1) 1.3.2 port optical fibre or optical fibre connector attached to a passive component for the entry and/or exit of the optical power 1.3.3 transfer matrix optical properties of a fibre optic circulator can be defined in terms of an n × n matrix of coefficients where n is the number of ports, and the coefficients represent the fractional optical power transferred between designated ports 1.3.9 polarization dependent loss (PDL) for polarization independent circulators, the maximum fluctuation of attenuation for any state of polarization of P j 1.3.10 polarization mode dispersion (PMD) for polarization independent circulators, the maximum delay between two perpendicular states of polarization when they pass through an optical circulator 1.3.11 conducting ports two ports i and j between which t ij is nominally greater than zero 1.3.12 isolated ports two ports i and j between which t ij is nominally zero, and a ij is nominally infinite 1.3.13 operating wavelength nominal wavelength, λ , at which a passive component is designed to operate with the specified performance 1.3.14 operating wavelength range; bandpass specified range of wavelengths from λ i min to λ i max about a nominal operating wavelength λ i , within which a passive component is designed to operate with the specified performance
