IEC 60317-19 pdf download.Specifications for particular types of winding wires
1 Scope
This International Standard specifies the requirements of solderable enamelled round copper winding wire of class 1 30 with a dual coating. The underlying coating is based on polyurethane resin, which may be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. The superimposed coating is based on polyamide resin. NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to enhance certain performance or application characteristics. Class 1 30 is a thermal class that requires a minimum temperature index of 1 30 and a heat shock temperature of at least 1 55 °C. The temperature in degrees Celsius corresponding to the temperature index is not necessarily that at which it is recommended that the wire be operated and this will depend on many factors, including the type of equipment involved. The range of nominal conductor diameters covered by this standard is: – – Grade 1 : 0,050 mm up to and including 1 ,600 mm; Grade 2: 0,050 mm up to and including 2,000 mm. The nominal conductor diameters are specified in clause 4 of IEC 6031 7-0-1 .
2 Normative references
The following standard contains provisions which, through reference in this text, constitute provisions of this International Standard. At the time of publication, the edition indicated was valid. All standards are subject to revision, and parties to agreements based on this International Standard are encouraged to investigate the possibility of applying the most recent edition of the standard indicated below. Members of IEC and ISO maintain registers of currently valid international standards. IEC 6031 7-0-1 :1 990, Specifications for particular types of winding wires – Part 0: General requirements – Section 1 : Enamelled round copper wire
4 Dimensions
See clause 4 of IEC 6031 7-0-1 .
5 Electrical resistance
See clause 5 of IEC 6031 7-0-1 .
6 Elongation
See clause 6 of IEC 6031 7-0-1 .
7 Springiness
See clause 7 of IEC 6031 7-0-1 .
8 Flexibility and adherence
See clause 8 of IEC 6031 7-0-1 , where the constant K used for the calculation of the number of revolutions for the peel test shall be 1 50 mm.
9 Heat shock
See clause 9 of IEC 6031 7-0-1 , where the minimum heat shock temperature shall be 1 55 °C.
10 Cut-through
No failure shall occur within 2 min at 1 70 °C.
11 Resistance to abrasion (nominal conductor diameters from 0,250 mm up to and including 2,000 mm)
The wire shall meet the requirements given in table 1 .
